Analyzers

The Hioki PW8001 High-Precision Power Analyzer sets the benchmark for precision power analysis, offering unmatched accuracy and flexibility for evaluating motor and inverter efficiency. Supporting DC and frequencies from 0.1 Hz to 5 MHz, it features an 8-channel measurement capacity, enabling simultaneous analysis of complex systems like EV drivetrains, renewable energy sources, and high-efficiency SiC/GaN semiconductors.

Equipped with advanced features such as automatic phase correction, intuitive Power Spectrum Analysis (PSA), and CAN/CAN FD integration, the PW8001 excels in capturing high-speed switching power fluctuations and harmonics. Its compatibility with high-voltage systems (up to 1500 V) and seamless connectivity with industry-standard software like LabVIEW and MATLAB ensure it meets diverse testing needs. With its robust design, real-time waveform visualization, and comprehensive motor analysis functions, the PW8001 is the ultimate tool for power conversion efficiency analysis.

• The S type Channel card provides economical, high-performance power measurement with a basic 0.1% accuracy and enough bandwidth to handle waveforms up to 1.25 MHz.
• The A-type ultra-precision Channel card offers a 2-year accuracy rating of 0.03% of reading and bandwidth up to 1.25 MHz.
• The W type Wideband Channel card performs precision power measurements on the toughest real-world waveforms, with sampling speed fast enough to tame waveforms up to 5Mhz

• High Power Accuracy of 0.045% For All Channels
• Improved Voltage and Current Self-Heating Adders
• Faster Sampling Rates & Bandwidth Performance
• Greater Harmonic Frequencies

• Ultra High Power Accuracy of 0.024% For All Channels
• Improved Voltage and Current Self-Heating Adders
• Faster Sampling Rates & Bandwidth Performance
• Greater Harmonic Frequencies

3-Phase 4-Wire Power Quality Analyzer Compliant to IEC61000-4-30 Class A Standards with Dynamic 1300V Range, Harmonic and Inter-harmonics Analysis Capabilities
