CT6830 AC/DC Current Probe for High-Accuracy Low Current Measurement
The CT6830 AC/DC Current Probe is engineered for engineers and technicians who require precise current measurement in compact and demanding environments. Designed as one of the smallest current sensors available, it offers a powerful combination of accuracy, stability, and ease of installation, even in locations with dense or complex wiring.
Compact Design Advantage
Space limitations are a common challenge in modern electrical and electronic systems. The CT6830 AC/DC Current Probe features a slim φ5 mm clamp diameter that allows effortless installation in confined locations where conventional probes cannot fit. Its compact form factor enables multiple sensors to be installed side by side, making it ideal for multi-channel measurements and detailed system analysis.
Accuracy and Reliability
Despite its small size, the CT6830 AC/DC Current Probe delivers excellent measurement accuracy for low-level currents up to 2 A AC/DC. Its non-contact sensing design ensures safe operation while maintaining measurement integrity. This makes it particularly suitable for applications requiring precise DC current monitoring without interfering with the conductor.
Performance in Variable Temperatures
Environmental stability is critical for reliable measurement results. The CT6830 AC/DC Current Probe operates consistently across a broad temperature range from −40°C to 85°C. This wide operating range allows accurate low-level DC current measurement even in environments where ambient temperature fluctuates significantly, such as automotive systems, power electronics, and industrial equipment.
Application Flexibility
Thanks to its compact size, high accuracy, and temperature stability, the CT6830 AC/DC Current Probe is well suited for precision testing, research and development, and diagnostic applications. It integrates easily with compatible measurement instruments, supporting efficient testing workflows without sacrificing accuracy or safety.
Technical Specifications Table
| Specification | Details |
| Product Name | CT6830 AC/DC Current Probe |
| Rated Current | 2 A AC/DC |
| Measurement Type | Non-contact current sensing |
| Clamp Conductor Diameter | φ5 mm |
| Operating Temperature Range | −40°C to 85°C |
| Accuracy | High accuracy for low-level DC current |
| Installation | Suitable for confined and complex wiring |
| Typical Applications | Precision testing, multi-sensor measurement |
| Model Number | CT6830 |
