Precision Performance with the Aim-TTi TGR205x RF Signal Generator
The Aim-TTi TGR205x RF Signal Generator is a high-performance, dual-model RF source designed for laboratories, R&D environments, and production testing. Offering frequency coverage from 150 kHz to 3 GHz, this series combines exceptional signal quality, flexibility, and intuitive control—all at an affordable cost.
Unmatched Frequency Accuracy and Signal Purity
Engineered for precision, the TGR205x provides 1 ppm frequency accuracy and less than 1 ppm drift within the first year. With phase noise better than -117 dBc/Hz (typical) at 1 GHz and 10 kHz offset, it ensures ultra-clean signals for even the most demanding applications. Its wide amplitude range from -127 dBm to +13 dBm with fine 0.1 dB resolution allows precise level control across diverse testing scenarios.
Comprehensive Modulation and Sweep Capabilities
This signal generator supports both analog (AM, FM, PM) and digital modulations, including ASK, OOK, FSK, 3FSK, 4FSK, GFSK, MSK, GMSK, HMSK, and PSK (optional). A built-in modulation waveform output enhances flexibility, while the internal waveform generator can produce sine, square, ramp, triangle, PRBS, and user-defined patterns.
For dynamic testing, it features fast amplitude and frequency sweeps with a settling time of just 5 ms and multiple triggering options—making it ideal for characterizing RF components, communication systems, and signal chains.
Intuitive Interface and Connectivity
The color touch screen interface simplifies setup and operation, allowing users to manage parameters quickly and efficiently. The TGR205x offers full remote control through USB, LAN (LXI), and optional GPIB, with SCPI compatibility for easy integration into automated test systems. Its compact design and compatibility with previous Aim-TTi generators make it a practical upgrade for both educational and professional environments.
Built for Modern RF Applications
Whether used for R&D, education, or production testing, the TGR205x RF Signal Generator delivers reliable, accurate, and clean RF signals. It’s an indispensable tool for engineers seeking precision and performance in one intelligent platform.
Technical Specifications Table
| Parameter | Specification |
| Model | TGR205x RF Signal Generator |
| Variants | TGR2051 (1.5 GHz), TGR2053 (3 GHz) |
| Frequency Range | 150 kHz to 1.5/3 GHz |
| Frequency Accuracy | ±1 ppm |
| Frequency Drift (1 Year) | < 1 ppm |
| Phase Noise | < -117 dBc/Hz at 1 GHz (10 kHz offset) |
| Amplitude Range | -127 dBm to +13 dBm |
| Amplitude Resolution | 0.1 dBm |
| Modulations | AM, FM, PM (analog), ASK, OOK, FSK, GFSK, MSK, GMSK, HMSK, PSK (digital) |
| Sweep Settling Time | 5 ms |
| Waveform Types | Sine, Square, Ramp, Triangle, PRBS, Custom |
| Display | Color Touch Screen |
| Interfaces | USB, LAN (LXI), Optional GPIB |
| Compatibility | Backward-compatible with previous Aim-TTi RF generators |
| Applications | RF design, education, testing, production environments |
