Description
The FPP2.3/1.5 M Field Probe Positioner is engineered for laboratories and EMC testing facilities that require fast, accurate, and repeatable field homogeneity measurements. This single axial positioner enables fully automated movement of up to four field probes across four horizontal positions, reducing traditional calibration times dramatically. With its ability to perform 16-point uniform field calibrations in a fraction of the time, tests that used to take days can now be completed in under an hour.
Constructed mainly from PVC and reinforced fiberglass, the FPP2.3/1.5 M minimizes metal components, reducing potential interference. The mechanical design includes limit switches and a robust drive system to ensure reliability during continuous operation. The system accommodates a load capacity of 3 kg and offers high positioning accuracy of ±0.5 cm, ensuring precise measurements every time.
The remote control interface via LAN (TCP/IP) integrates seamlessly with FCU 3.0 or NCD Controllers, allowing full automation and optional software-driven adjustments. Positioning speed is fully adjustable to optimize testing efficiency, with ranges up to 35 cm/s. Kevlar-reinforced toothed belts drive smooth, reliable probe movement while keeping metal interference minimal.
Ideal for automotive, avionics, industrial, and wireless telecom markets, the FPP2.3/1.5 M ensures compliance with international standards including CISPR 22/32 and IEC/EN 61000-4-3. By combining fast response field probes and power meters, users can maximize throughput, reduce labor costs, and maintain consistent measurement quality.
The system includes essential accessories such as a 3-meter power supply cable and service manual, making setup straightforward. Its versatility and precision make the FPP2.3/1.5 M an indispensable tool for EMC testing facilities seeking high-efficiency, automated calibration solutions.
Technical Specifications
| Feature | FPP2.3/1.5 M |
| Field Probe Height | 4 fixed positions up to 2.3 m |
| Horizontal Range | 1.5 m |
| Total Length | 2.7 m |
| Load Capacity | 3 kg |
| Positioning Accuracy | ±0.5 cm |
| Positioning Speed | 1–35 cm/s (adjustable) |
| Material | Plastic & reinforced fiberglass |
| Motor | DC stepper motor |
| Drive | Kevlar-reinforced toothed belt |
| Voltage | 110–230 VAC, 50/60 Hz |
| Control Interface | LAN (TCP/IP), IEEE optional with NCD |
| Operating Temperature | 10°C – 35°C |
| Total Weight | ~60 kg |
| Accessories | Service manual, 3 m power cable, Controller |
