Description
LS3081D RF Signal Generator
The LS3081D RF Analog Signal Generator Module from Tabor Electronics’ Lucid Series is engineered for high-precision RF testing in both laboratory and field environments. With a maximum frequency of 3GHz, this compact, modular unit delivers high signal fidelity, making it ideal for communication systems, radar applications, and automated test equipment (ATE). Its small footprint allows deployment in desktop, benchtop, rackmount, or portable setups, providing flexibility for a wide range of test scenarios.
Fast Frequency Switching
Minimizing test cycle latency is critical in modern RF testing. The LS3081D achieves switching speeds of less than 100µs, drastically reducing dead time between frequency hops. This enables faster sweep rates and significantly improves measurement throughput for high-volume testing, without compromising signal quality.
Superior Signal Integrity and Modulation
Signal purity is essential in high-precision testing. The LS3081D offers a typical phase noise of -138dBc/Hz at 1GHz (10 kHz offset), ensuring clean, reliable signals. The generator supports a comprehensive suite of modulation options, including AM, FM, PM, sweep, and pulse modulation. External baseband signals can also be applied, giving engineers full flexibility for advanced testing scenarios.
Modular Platform and Flexible Control
The LS3081D integrates seamlessly into modern test systems. It supports SCPI and VISA standards and can be controlled remotely via LAN, USB, or SPI interfaces. Engineers can use Python, MATLAB, C#/C++, or LabVIEW for automation and integration. The included virtual front panel allows intuitive control locally or over a network.
Applications
Engineers and technicians use the LS3081D for receiver testing, multi-tone analysis, communications testing, radar system validation, and quantum experiments. Its compact modular design ensures high performance while minimizing lab space and cost, making it a versatile solution for precise RF signal generation.
Technical Specifications
| Parameter | Specification |
| Frequency Range | DC to 3GHz |
| Channels | Single, optional multi-channel |
| Switching Speed | <100µs |
| Modulation | AM, FM, PM, Sweep, Pulse |
| Phase Noise | -138dBc/Hz @1GHz, 10 kHz offset |
| Form Factor | Modular – Desktop, Benchtop, Rackmount, Portable |
| Control Interfaces | SCPI, VISA, LAN, USB, SPI |
| Software Support | Python, MATLAB, C#/C++, LabVIEW |
| Optional Packages | MOD, PLS, PAT, LP, FS, EMU, STN, WE |
| Applications | RF testing, ATE, radar, communications, high-precision labs |
