Description
LS6082B Signal Generator
The LS6082B 6GHz Dual Channel RF Analog Signal Generator is engineered for engineers who require synchronized dual outputs with exceptional signal clarity. As part of the Lucid series, the LS6082B provides reliable RF generation, fast switching performance, and advanced modulation features in a compact benchtop instrument designed for both research and automated production environments.
Speed and Switching Performance
The LS6082B Signal Generator features frequency switching of less than 100µs. This fast settling time significantly reduces idle delays between frequency steps, improving sweep efficiency and overall test throughput. In automated test equipment environments, this translates directly into reduced production time and higher operational efficiency. Engineers performing multi-frequency measurements benefit from rapid transitions without compromising stability.
Purity and Stability
Clean signal generation is critical for high accuracy RF testing. The LS6082B Signal Generator delivers a typical SSB phase noise of -138 dBc/Hz at 1GHz with a 10 kHz offset. This low noise performance ensures minimal signal distortion and reliable measurement accuracy. It is particularly valuable for intermodulation distortion testing, local oscillator applications, DAC and ADC clock validation, and receiver performance evaluation.
Modulation Capabilities
The LS6082B Signal Generator supports a full range of modulation schemes including AM, FM, PM, Sweep, and Pulse modulation. Pulse modulation offers up to 60 dBc on and off ratio for radar and communication signal simulation. Both internal and external baseband modulation are supported, giving engineers flexibility to integrate custom waveform requirements. Dual-channel capability makes it ideal for phase-coherent experiments, mixer testing, and multi-tone signal generation.
Control and Integration
Integration into modern lab setups is simple with SCPI and VISA programming standards. The LS6082B Signal Generator can be controlled via LAN or USB using Python, MATLAB, C#, C++, or LabVIEW. The virtual front panel provides intuitive control locally or across a network, supporting flexible deployment in standalone or automated systems.
Applications
The LS6082B Signal Generator is ideal for communications system validation, radar subsystem development, RF component testing, phased array research, and automated manufacturing environments. Its combination of dual-channel flexibility and high signal integrity makes it a dependable solution for demanding RF tasks.
Technical Specifications
| Parameter | Specification |
| Model | LS6082B |
| Frequency Range | DC to 6 GHz |
| Channels | Dual Channel |
| Frequency Switching Speed | <100 µs |
| Phase Noise | -138 dBc/Hz at 1GHz, 10 kHz offset |
| Modulation Types | AM, FM, PM, Sweep, Pulse |
| Pulse Modulation On/Off Ratio | 60 dBc |
| Control Interfaces | LAN, USB |
| Programming Support | SCPI, VISA, Python, MATLAB, C#, C++, LabVIEW |
| Platform | Compact Benchtop Modular |
| Applications | Radar, Communications, RF Testing, ATE |
| Available Options | PLS, PAT, ELP, EPR, FS, EMU, WE |
| Accessories | W Rack Mount Kit |
