Description
P9084D Proteus AWG for next generation RF and quantum systems
The Tabor Proteus P9084D is engineered for engineers and researchers who need extreme speed, precision, and adaptability in waveform generation. It is not just an arbitrary waveform generator, but a real time signal intelligence platform that can listen, respond, and adapt dynamically to changing signal environments. Built on an advanced software defined radio architecture, it supports cutting edge applications across defense, communications, physics, and quantum research.
With a powerful 9GS/s sampling rate and 4 synchronized output channels, the P9084D enables highly accurate multi channel waveform generation with tight phase coherence. Its 4GS memory depth allows storage and playback of complex waveform sequences without interruption, making it ideal for long duration simulations and high density signal environments.
A defining advantage of the P9084D is its real time feedback control system. Unlike traditional waveform generators that rely on preloaded sequences, this system processes incoming signals and immediately adjusts output behavior. This reduces latency significantly and enables closed loop operation for applications such as electronic warfare simulation, radar target generation, and qubit control systems.
The task based sequencing engine replaces linear waveform playback with a conditional logic structure. This allows the system to react to external triggers or received signals and instantly switch waveform states. As a result, users can design intelligent RF scenarios that behave dynamically rather than statically.
Its PCIe based architecture ensures ultra fast data transfer between memory and processing units, enabling continuous streaming and real time waveform updates. Combined with excellent phase noise performance and integrated digital IQ processing, the P9084D delivers highly stable and clean signal output even in complex RF environments.
From laboratory research to defense level testing systems, the P9084D Proteus AWG provides unmatched flexibility and computational waveform control in a compact, high density platform.
Technical Specifications
| Parameter | Specification |
| Model | P9084D |
| Sampling Rate | 9 GS/s |
| Resolution | 8-bit |
| Output Channels | 4 |
| Waveform Memory | 4 GS |
| Markers | 16 |
| Architecture | SDR based Proteus platform |
| Data Transfer | PCIe high speed backplane |
| Signal Processing | Real time FPGA based feedback |
| Sequencing Type | Task driven conditional state machine |
| Output Type | RF DAC based waveform generation |
| Key Capability | Real time adaptive waveform control |
| Applications | EW simulation, quantum control, RF testing, radar systems |
