Description
The TT 0.3 PF Turn Table is a precision-engineered solution for electromagnetic compatibility (EMC) testing in anechoic and semi-anechoic chambers. Designed for free-standing floor installation, this turntable ensures reliable performance in industries such as automotive, telecommunications, medical electronics, power generation, and IT equipment testing.
With a diameter of 0.3 m and a load capacity of 50 kg, the TT 0.3 PF is suitable for a wide range of test setups, from lightweight devices to medium-sized equipment. The surface is crafted from integral skin-foam PVC sheets, ensuring durability while maintaining a stable and low-resonance platform for precise measurements.
A key feature is its 50 mm central opening, which allows convenient insertion of power supply cables for real-time testing of devices. The synchronous servo motor, paired with a toothed belt and worm gear drive, enables smooth and accurate rotation. Users can adjust the rotation speed from 0.1 rpm to 2.5 rpm, while the positioning accuracy of ±0.5° guarantees precise alignment during EMC evaluations.
The TT 0.3 PF offers advanced remote operation capabilities. Equipped with a LAN (TCP/IP) interface, it can be seamlessly controlled via FCU3.0 or NCD Controllers, enabling automation and reducing manual intervention. Interference suppression is built-in, with compliance to DIN EN 55011:2018-05 class B, ensuring reliable performance under stringent testing conditions.
Additional benefits include a temperature operating range of 10°C to 35°C, compact 25 kg weight, and low elevation tolerance under 3 mm. Its compatibility with multiple controller types and fiber optic communication ensures versatility across different testing environments.
For engineers and laboratories demanding accuracy, durability, and ease of integration, the TT 0.3 PF Turn Table is a trusted solution that enhances EMC testing efficiency and reliability.
Technical Specifications
| Specification | Value |
| Diameter | 0.3 m |
| Load Capacity | 50 kg |
| Height | 190 mm |
| Material | Integral PVC skin-foam sheets |
| Rotation Speed | 0.1 – 2.5 rpm |
| Positioning Accuracy | ±0.5° |
| Rotation Angle | -200° to 400° |
| Motor Type | Synchronous servo motor |
| Drive Mechanism | Toothed belt + worm gear |
| Elevation Tolerance | < 3 mm |
| Voltage Input | 110–230 VAC, 50/60 Hz |
| Max Current Consumption | 16 A |
| RCD Required | 300 mA |
| Control Cable | Fiber optic |
| Remote Control Options | LAN (TCP/IP), IEEE with NCD |
| Interference Suppression | 20 dB under DIN EN 55011:2018-05 class B |
| Operating Temperature | 10°C – 35°C |
| Total Weight | ~25 kg |
| Included Accessories | Service manual, 3 m power cable |
| Compatible Controllers | FCU3.0, FCU3.0S, FCU3.0S-LITE, NCD 3.0 |
