Products

  • HVR 1200RG Ripple Generator
    HVR 1200RG Ripple Generator
    Quick View
    AE Techron HVR 1200RG Ripple Generator

    The HVR 1200RG Ripple Generator is a powerful, next-gen solution tailored for electric vehicle high-voltage testing. Designed for use with traction inverters and HIL test stands, this rugged system delivers unmatched ripple current and voltage capabilities across a wide frequency range.

    Key Features:

    • Ripple Current Output: Up to 600 A peak
    • Voltage Range: 0 – 150 Vp (300 Vp-p)
    • Wide Frequency Support: 150 Hz to 300 kHz
    • DC Voltage Compatibility: 0 – 1200 V (or up to 2000 V in bridged mode)
    • Data Monitoring: Real-time tracking of voltage, current, and impedance
    • Built-In Protections: Handles short circuits and noisy DUTs effortlessly
    • Modular & Expandable: Configurable for current and future EV standards
    • Noise-Resistant: Engineered to operate accurately in high-noise environments



    Learn More
  • I-prober 520
    I-prober 520
    Quick View
    Aim-TTi I-prober 520
    • Current measurement from insulated probing of conductor
    • Suitable for observation and measurement of current in PCB tracks, component leads and ground planes
    • Wide dynamic range of 10mA to 20A peak to peak
    • Wide bandwidth of DC to 5MHz
    • Low noise figure equivalent to <6mA rms at full B/W
    • Safety rated to 300V Cat II (600V Cat 1)
    • Suitable for connection to any oscilloscope
    • High accuracy general purpose H-field probe
    • Converts to ‘closed magnetic circuit’ current probe



    Learn More
  • IMPEDANCE ANALYZER IM3570
    IMPEDANCE ANALYZER IM3570
    Quick View
    HIOKI E E CORPORATION IMPEDANCE ANALYZER IM3570 USD $ 11,179.47

    A high-speed, high-precision LCR meter ideal for low-ESR and impedance testing in advanced electronic components like polymer capacitors, inductors, and piezoelectric elements.

    Key Features:

    • Continuous LCR/DCR/sweep measurements with one instrument
    • Ultra-fast testing speeds: 1.5 ms (1 kHz), 0.5 ms (100 kHz)
    • High accuracy: ±0.08% basic accuracy for Z parameter
    • Ideal for low-ESR measurement of functional polymer capacitors
    • Suitable for resonance testing of piezoelectric elements
    • Accurate DCR and L-Q testing of inductors, coils, and transformers
    Learn More
  • IMPEDANCE ANALYZER IM7580A
    IMPEDANCE ANALYZER IM7580A - 2
    Quick View
    HIOKI E E CORPORATION IMPEDANCE ANALYZER IM7580A USD $ 14,517.66

    The Hioki IM7580A is a compact, high-speed impedance analyzer for 1 MHz to 300 MHz testing, ideal for both production and R&D. It works seamlessly with the IM9201 SMD fixture for reliable component testing.

    Key Features:

    • 1 MHz to 300 MHz frequency range
    • 0.5 ms test speed
    • ±0.72% basic accuracy
    • Compact half-rack size with palm-sized test head
    • Reliable contact check functions
    • Frequency, level, and time sweeps in Analyzer Mode
    • RF I-V method for precise measurement
    Learn More
  • IMPEDANCE ANALYZER IM7581
    IMPEDANCE ANALYZER IM7581 - 2
    Quick View
    HIOKI E E CORPORATION IMPEDANCE ANALYZER IM7581 USD $ 17,671.64

    The Hioki IM7581 is a compact, high-speed impedance analyzer designed for accurate testing from 100 kHz to 300 MHz. It’s ideal for both production and development environments.

    Key Features:

    • 100 kHz to 300 MHz frequency range
    • 0.5 ms fastest test speed
    • ±0.72% basic accuracy
    • Compact half-rack size, palm-sized test head
    • Reliable contact check via DCR, Hi-Z reject, or waveform judgment
    • Supports frequency, level, and time sweeps in Analyzer Mode
    • Uses RF I-V method for precise measurement
    Learn More
  • Impedance Analyzer IM7587 3 GHz
    Impedance Analyzer IM7587 3 GHz
    Quick View
    HIOKI E E CORPORATION IMPEDANCE ANALYZER IM7587 3 GHz USD $ 29,638.88

    The Hioki Impedance Analyzer IM7587 3 GHz provides precision, speed, and versatility for impedance measurements from 1 MHz to 3 GHz, ideal for both R&D and mass production applications in electronic component testing.

    Key Features:

    • Frequency range: 1 MHz to 3 GHz
    • Test speed: 0.5 ms
    • Measurement variability: 0.07%
    • Basic accuracy: ±0.65% reading
    • RF I-V measurement technique
    • Compact half-rack design with palm-sized test head
    • Robust contact check capabilities
    • Analyzer mode: frequency and level sweeps, time interval measurements
    Learn More
  • LCR Meters
    LCR Meters
    Quick View
    Teledyne LeCroy LCR Meters

    Teledyne Test Tools LCR Meters offer precision testing in a compact form, perfect for R&D labs and production lines.

    Key Features:

    • 3.5” high-resolution color LCD display
    • Test frequency up to 300 kHz with continuous output
    • 0.05% basic measurement accuracy
    • Spot or full frequency range with OPEN/SHORT correction
    • Automatic Level Control (ALC) for consistent voltage on components like MLCCs
    • Measure up to 4 parameters simultaneously
    • DCR measurement & built-in ±2.5 V DC bias
    • PASS/FAIL indicator and 10-bin sorting function
    • List measurement for automated test sweeps (up to 10 points)
    • Interfaces: RS-232C, USB, handler, and USB storage
    • Compact 2U, 1/2 rack size for automated test setups
    Learn More
  • MEMORY HiCORDER MR6000
    Quick View
    HIOKI E E CORPORATION MEMORY HiCORDER MR6000 USD $ 15,210.78

    The Hioki MR6000 Memory HiCorder sets a new benchmark in waveform recording, combining cutting-edge technology, intuitive design, and world-class performance. Built from the ground up, it’s engineered to tackle both current and future measurement challenges with ease and precision.

    Key Features:

    • Large, intuitive touch panel for efficient and user-friendly operation
    • Simultaneous multi-channel isolation measurement at up to 200 MS/s (with High Speed Analog Unit U8976)
    • Significantly faster data saving for a seamless experience
    • Real-time data saving without interrupting ongoing measurements
    Learn More
  • MEMORY HiCORDER MR8741 - 1
    Quick View
    HIOKI E E CORPORATION MEMORY HiCORDER MR8741 USD $ 6,710.59

    The Hioki Rack-mounted Multi-channel System Recorder (MR8741/MR8740) is a powerful, high-speed, single-device solution for waveform recording and generation. Ideal for test systems, it offers high-resolution, isolated multi-channel measurements with fast sampling capabilities.

    Key Features:

    • Integrated waveform recording and generation in one device
    • Equipped with DVM Unit MR8990 for high-accuracy 24-bit resolution measurements
    • Supports up to 16 channels (MR8741) for multi-channel testing
    • Isolated input between channels and from input to chassis (up to 300 V AC/DC)
    • High-speed sampling up to 20 MS/s
    • Compact rack-mountable design (4U height, under 180 mm depth)
    • Monitor display and setting access via DVI-D and mouse
    • Enables remote measurement and control via LAN
    • Browser-based screen monitoring or advanced control via Hioki 9333 LAN Communicator
    Learn More
  • MEMORY HiCORDER MR8827 - 1
    MEMORY HiCORDER MR8827 - 2
    Quick View
    HIOKI E E CORPORATION MEMORY HiCORDER MR8827 USD $ 11,073.17

    The Hioki Memory Recorder is a high-speed, fully-isolated data acquisition system designed for precise and simultaneous measurement of multiple analog and logic signals. Ideal for testing, simulation, and system diagnostics, it combines waveform generation and recording in one powerful unit.

    Key Features:

    • Generate and record waveforms using a single device
    • Simulate issues by outputting previously recorded problematic waveforms to test devices
    • Supports 32 analog + 32 logic channels, expandable to 28 analog + 64 logic channels
    • High-speed sampling up to 20 MS/s with fully isolated inputs
    • Ensures safe measurement with complete analog input isolation
    • Equipped with a large-capacity 512M-word memory
    • Simultaneously measures high voltage and ultra-low voltage system signals



    Learn More
  • Milli Ohm Meter
    Milli Ohm Meter
    Quick View
    Teledyne LeCroy Milli Ohm Meter

    Teledyne Test Tools Milli Ohm Meter offers high-precision low-resistance measurement with advanced drive modes, temperature compensation, and fast sampling.

    Key Features:

    • 50,000-count high-resolution display
    • 3.5″ TFT LCD (320×240)
    • 0.05% measurement accuracy
    • 1 Amp test current with 0.1 μΩ resolution
    • Fast 60 readings per second
    • Four-wire measurement method
    • Temperature compensation and delayed measurement
    • 20-panel memory settings
    • Dry circuit testing (T3MIL50X only)
    • USB, RS-232C, and EXT I/O interfaces
    • Multiple drive modes: DC+, DC-, Pulsed, PWM (T3MIL50X)



    Learn More
  • PS 66-55 Battery Supply
    PS 66-55 Battery Supply
    Quick View
    Absolute EMC PS 66-55 Battery Supply

    A compact, high-performance power supply for automotive EMC and battery voltage simulation.

    Key Features:

    • Battery simulator for 12V, 24V, 42V, and 48V systems
    • Output: 0–66V / 0–55A (max)
    • Fast voltage rise time up to 100V/µs
    • ISO 7637-2 and ISO 16750-2 compliant
    • Remote control via CAR-Remote Software
    • Impulse Recording Function (IRF) included
    • Compact 19-inch desktop form (15 kg only)
    • Overvoltage and thermal protection
    • Slew rate: 10V/µs with fan cooling system
    • Compatible with HILO CAR-SYS test systems



    Learn More
  • PS 74-220 Battery Simulator
    PS 74-220 Battery Simulator
    Quick View
    Absolute EMC PS 74-220 Battery Simulator

    High-performance power simulator designed for advanced EMC and automotive voltage testing.

    Key Features:

    • Supports 12V, 24V, 42V, 48V, and 70V automotive systems
    • Battery simulation with up to 220A current
    • Fast voltage rise time up to 100V/µs
    • ISO 7637-2 and ISO 16750-2 compliant
    • Integrated Impulse Recording Function (IRF)
    • Full remote control via CAR-Remote software
    • Ethernet interface and built-in safety interlock
    • Cooling via fans and heat sink for reliable operation
    • Compact 19-inch rackmount desktop system (60 kg)
    • Overvoltage and thermal protection included



    Learn More
  • PSA Series 3 Spectrum Analyzer - 1
    PSA Series 3 Spectrum Analyzer - 2
    Quick View
    Aim-TTi PSA Series 3 Spectrum Analyzer

    Experience precision RF signal analysis on the go with this lightweight, handheld analyzer designed for both lab and field use.

    Key Features:

    • Frequency range: 1MHz to 1.3GHz (PSA1303) or 2.7GHz (PSA2703)
    • RBW: 300Hz to 10MHz
    • -115dBm typical noise floor
    • Dual markers with absolute/difference values
    • AM/FM demodulation in zero span
    • Auto-find & smart marker peak tracking
    • USB for waveform saving and PC connection
    • Live, View, and Reference trace modes
    • 6-hour lithium-ion battery operation
    • Weighs just 0.58 kg
    • Optional U01 Upgrade: Limit lines, data logging, triggering, compensation tables



    Learn More
  • PSA Series 5 Spectrum Analyzer - 1
    PSA Series 5 Spectrum Analyzer - 2
    Quick View
    Aim-TTi PSA Series 5 Spectrum Analyzer

    High-performance, battery-powered spectrum analyzers ideal for RF engineers and field use.

    Key Features:

    • Frequency range: 10MHz to 3.6GHz or 6.0GHz
    • -120dBm typical noise floor
    • Resolution bandwidths from 300Hz to 10MHz
    • AM/FM audio demodulation with zero span
    • Live, View & Reference traces with markers
    • Smart marker tracking with peak detection
    • USB data logging & real-time PC view
    • Compact, lightweight (0.56 kg) with >3hr battery
    • Optional U02 features: limit lines, OBW, ACPR, AM/FM waveform demodulation



    Learn More
  • RGB ACTIVE MATRIX - 10" Transparent Display
    RGB ACTIVE MATRIX - 10" Transparent Display
    Quick View
    VueReal RGB ACTIVE MATRIX – 10″ Transparent Display

    Showcasing a large 10” panel withultra-bright, energy-efficientmicroLED technology, deliveringdynamic visuals and seamlessintegration for next-generationintelligent vehicles.

    Ket Features:

    • OVERVIEWUltra-High Brightness: Engineered to perform in a widerange of lighting conditions, ensuring excellent visibility inboth indoor and outdoor environments.
    • Robust Durability: Built to withstand demandingconditions for long-term reliability.
    • Ultra-Thin & Lightweight: Designed for seamlessintegration into compact spaces, leveraging microLED’sinherently slim profile without compromisingperformance.
    • Vibrant RGB Color Reproduction: Delivers rich, high-contrast visuals with precise color accuracy, enhancingvisuals for display applications.



    Learn More
